Product Overview
Optics (Day Channel)
- Magnification: 1×
- Exit Pupil Diameter: 14 mm
- Exit Pupil Distance: 25 mm
- Diopter Adjustment: -3 to +2 D
Image Intensifier (I² / Night Vision)
- Generation: Gen 2+
- Resolution: 64 lp/mm
- Field of View: 40°
- Lens System: f/1.2, 25 mm
- Range of Focus: 0.27 yd to infinity
- Brightness Control: Yes
- Bright Source Protection: Yes
- Infrared Illuminator: Built-in
Thermal Imaging
- Type: VOx Uncooled
- Resolution: 640 × 512 pixels
- Pixel Pitch: 12 μm
- NETD: <30 mK
- Frame Rate: 50 Hz
- Lens System: f/1.1, 16 mm
- Field of View: 25.8° × 19.1°
- Brightness Control: Yes
- Polarity Modes: White Hot / Orange Hot
Enhanced Modes
- Modes: Outline, Highlight, Breath
- Azimuth Indication: Yes
Display
- Type: OLED
- Resolution: 800 × 600 pixels
Detection Range
- 1500 m / 1640 yd
Environmental Specifications
- Protection Rating: IP67
- Operating Temperature: -40°F to +122°F
Power
- Battery Type: 18650 ×2
- Operating Time:
- Enhanced Display: ≥ 8 hours
- I² Mode: up to 60 hours
Physical Specifications
- Dimensions: 4.2 × 4.5 × 3.3 inches
- Weight:
- Main Body: 1.26 lb
- Battery Pack: ≤ 0.23 lb (without battery)
Specs
| Weight | 1 lb |
|---|---|
| Dimensions (W x H x D) | 8 x 6 x 6 in |
